43" Internet Floor standing AD player-ADV4302N
Quick Specifications
- Model No.ADV4302N
- LCD43" TFT 1920*1080 IPS
- Touch Screen43" capacitive touch screen,Support 10-points multi-touch.
- CPUType Quad Core ARM Cortex [email protected] And Mali T764
- Model numberRK3288 Multimedia HD video decoder (4K@60fps and FHD 1080p@60fps) HD video encoder (1080p @ 30fps) GPU offers 3D graphic with OpenGL ES1/2/3.0 and OpenVG 1.1 DriectX11 2D/3D GPU (Mali T764) Strong Power Manage Unit(PMU) I2S Master & Slave Interface for Audio
- DDR/FlashDual Channel DDR3/L 2G DDR
Product Overview
Detailed description is not available.
Technical Specifications
Model No.
ADV4302N
LCD
43" TFT 1920*1080 IPS
Touch Screen
43" capacitive touch screen,Support 10-points multi-touch.
CPU
Type Quad Core ARM Cortex [email protected] And Mali T764
Model number
RK3288 Multimedia HD video decoder (4K@60fps and FHD 1080p@60fps) HD video encoder (1080p @ 30fps) GPU offers 3D graphic with OpenGL ES1/2/3.0 and OpenVG 1.1 DriectX11 2D/3D GPU (Mali T764) Strong Power Manage Unit(PMU) I2S Master & Slave Interface for Audio
DDR/Flash
Dual Channel DDR3/L 2G DDR
eMMC/NAND flash
16G/32G
Three-axis
Freescale MMA8452Q Micophone Built-in microphone
Operation System
OS Android 5.1.1
Linux Kernel
3.0.8+
Wi-Fi
WiFi AP6330 Module(Broadcom IEEE 802.11 a/b/g/n, Built-in WiFi(2.4G/5G)+Bluetooth 4.0 )
Ethernet
RJ45 RTL8211E 10M/100M /1000M
Standard Applications
Music MP3,WMA,WAV,OGG,AAC,FLAC,3GP…
Video Player
MPEG1/2/4,AVI,WMV,MKV,MOV,VP8, H.263/264/265…
Gallery
JPG,BMP,PNG…
Browser
Internet browse
Play Store
Apps in Google Play Store
Adobe Flash Player
V11.1 or later
HTML5
Support
DLNA
Digital Living Network Alliance
Multi Window
Support
I/O
Mini USB port 1 For OTG( TP control signal out as HDMI input)
USB TYPE A
USB2.0*2
DC Power
DC 19V 3A, Diameter 5mm
Button
Power
HDMI
HDMI INPUT(OPTIONAL, extra cost USD 10)
SD card slot
For SD card
Earphone
20mW @ 16 Ohms ,Stereo,Diameter 3.5mm earphone jack
Speaker
Built-in speaker upto 4Ω/5W x 2
Camera
Optional front camera 30W Or 200W
Size & Other
Size TBD
Net Weight
TBD
VESA wall mounting
200 mm x 170 mm
Gross Weight
TBD
Package Size
TBD
Housing materia
Metal
