WD1012T 10.1" Dual-screen Signage
Quick Specifications
- Diagonal Size10.1-inch (LCD)
- Resolution1280 x 800 pixels
- Aspect Ratio16:10
- Viewing AngleR/L 85/85, U/D 85/85
- Display ModeNormally black
- Contrast Ratio800:1
Product Overview
Detailed description is not available.
Technical Specifications
Diagonal Size
10.1-inch (LCD)
Resolution
1280 x 800 pixels
Aspect Ratio
16:10
Viewing Angle
R/L 85/85, U/D 85/85
Display Mode
Normally black
Contrast Ratio
800:1
Luminance
250 nits
Number of Points
10-point
CPU
WD1012T: RK3288 Quad-core cortex A17; WD1028T: RK3568 Quad-core cortex A55
RAM
WD1012T: 2GB; WD1028T: 2GB (Optional 4GB)
ROM
WD1012T: 16GB; WD1028T: 16GB (Optional 32GB/64GB)
Operating System
WD1012T: Android 8.1/10.0; WD1028T: Android 11
Dimensions
239.3 x 162.9 x 131.97 mm (L × W × D)
Battery Capacity
Optional 4500mAh
WiFi
IEEE 802.11b/g/n
USB
USB 2.0 Host; USB for serial (TTL format)
USB Type-C
USB OTG Only
Card slot
TF, support up to 64GB
Power Port
DC power input
Video Format
MPEG-1, MPEG-2, MPEG-4, H.265, H.264, VC-1, VP8, etc., support up to 4K
Audio Format
MP3/WMA/AAC, etc
JPEG
Color
White
Speaker
3W*2
Microphone
Single microphone
Camera
Standard single camera 5.0MP, Option Dual camera 5.0MP
Language
Multi-language
Certificates
CE/FCC
Operating Temperature
0℃-40℃
Adapter
12V/5A
User Manual
×1
