Desktop Signages
WL1412T 14.1" Desktop Signage
Quick Specifications
- Diagonal Size14-inch (LCD)
- Resolution1920 x 1080 pixels
- Aspect Ratio16:9
- Viewing AngleR/L 85/85, U/D 85/85
- Display ModeNormally black
- Contrast Ratio800:1
Product Overview
Detailed description is not available.
Technical Specifications
Diagonal Size
14-inch (LCD)
Resolution
1920 x 1080 pixels
Aspect Ratio
16:9
Viewing Angle
R/L 85/85, U/D 85/85
Display Mode
Normally black
Contrast Ratio
800:1
Luminance
250 nits
Number of Points
10-point
CPU
WL1412T: RK3288 Quad-core cortex A17WL1413T: RK3399 Dual-core A72+Quad-core A53WL1416T: RK3566 Quad-
RAM
WL1412T: 2GBWL1413T: 2GB (Optional 4GB)WL1416T: 2GB (Optional 4GB)WL1418T: 16GB (Optional 32GB)
ROM
WL1412T: 16GBWL1413T: 16GB (Optional 32GB)WL1416T: 16GB (Optional 32GB)WL1418T: 16GB (Optional 32GB)
Operating System
WL1412T: Android 8.1/10.0WL1413T: Android 7.1/10.0WL1416T: Android 11WL1418T: Android 11
Dimensions
389.16 x 242.9 x 142.3 mm (L × W × D)
Battery Capacity
Optional 4500mAh
WiFi
WL1412T: IEEE 802.11b/g/nWL1413T: IEEE 802.11a/b/g/n/acWL1416T: IEEE 802.11b/g/nWL1418T: IEEE 802.11
USB
WL1413T: USB 3.0 HostWL1416T: USB 3.0 HostWL1418T: USB 3.0 Host
HDMI
HDMI output, up to 4K
Power Port
DC power input
Video Format
WL1412T: MPEG-1, MPEG-2, MPEG-4, H.265, H.264, VC-1, VP8, etc., support up to 4KWL1413T: MPEG-1, MPE
Audio Format
MP3/WMA/AAC, etc
WL1412T: JPEGWL1413T: JPEG/PNGWL1416T: JPEG/PNGWL1418T: JPEG/PNG
Color
White/Black
Speaker
3W*2
Microphone
WL1412T: Single microphoneWL1413T: Single microphoneWL1416T: Dual microphoneWL1418T: Standard dual m
NFC
Optional, NFC 13.56MHz, ISO14443A/ISO14443B/ISO15693/Mifare classic/Sony felica
Camera
WL1412T: Standard wide-angle 2.0MP, Optional binocular 5MPWL1413T: Standard wide-angle 2.0MP, Option
Language
Multi-language
Certificates
CE/FCC
Operating Temperature
0℃-40℃
