Touchscreen Signages 8"-55"
NW1493T 14" Touchscreen Signage
Quick Specifications
- Diagonal Size14-inch (LCD)
- Panel TypeIPS
- Resolution1920 x 1200 pixels
- Aspect Ratio16:9
- Number of Colors16.7M Colors
- Color Gamut45% NTSC
Product Overview
Detailed description is not available.
Technical Specifications
Diagonal Size
14-inch (LCD)
Panel Type
IPS
Resolution
1920 x 1200 pixels
Aspect Ratio
16:9
Number of Colors
16.7M Colors
Color Gamut
45% NTSC
Viewing Angle
R/L 85/85, U/D 85/85
Display Mode
Normally black
Contrast Ratio
700:1
Response Time
25ms
Back-light Type
Eled
Luminance
250 nits
Number of Points
10-point
Interface for Touch
USB
CPU
NW1493T: RK3399 Dual-core cortex A72+Quad-core cortex A53 / NW1496T: RK3566 Quad-core cortex A55 / NW1498T: RK3568 Quad-core cortex A55 / NW1495T: RK3588 Quad-core cortex A55+Quad-core cortex A76
RAM
NW1493T: 2GB (Optional 4GB) / NW1496T: 2GB (Optional 4GB) / NW1498T: 2GB (Optional 4GB) / NW1495T: 4GB (Optional 8GB)
ROM
NW1493T: 16GB (Optional 32GB) / NW1496T: 16GB (Optional 32GB) / NW1498T: 16GB (Optional 32GB) / NW1495T: 32GB (Optional 64GB)
Operating System
Android 12
Dimensions
336.2 x 209.3 x 27.6 mm (L × W × D)
WiFi
NW1493T: IEEE 802.11b/g/n/a/ac / NW1496T: IEEE 802.11b/g/n / NW1498T: IEEE 802.11b/g/n / NW1495T: IEEE 802.11b/g/n/a/ac/ax (wifi 6)
USB
NW1493T: USB 2.0 Host / NW1496T: USB 2.0 Host / NW1498T: USB 2.0 Host
USB
NW1493T: USB 3.0 Host / NW1496T: USB 3.0 Host / NW1498T: USB 3.0 Host / NW1495T: USB 3.0 Host*2
USB Type-C
NW1493T: Full Function (Except for charging function) / NW1496T: USB OTG Only / NW1498T: USB OTG Only / NW1495T: Full Function (Except for charging function)
HDMI
NW1493T: Support 800*600, 1024*768, 1280*720, 1280*800, 1280*1024, 1366*768, 1600*900, 1920*1080, etc / NW1496T: Support 800*600, 1024*768, 1280*720, 1280*800, 1280*1024, 1366*768, 1600*900, 1920*1080, etc / NW1498T: Support 800*600 ,1024*768, 1280*720, 1280*800, 1280*1024, 1366*768, 1600*900, 1920*1080, etc / NW1495T: Support 800*600, 1024*768, 1280*720, 1280*800, 1280*1024, 1366*768, 1600*900, 1920*1080, 3840*2160, etc
Power Port
DC power input
Video Format
NW1493T: MPEG-1, MPEG-2, MPEG-4, H.265, H.264, H.263, VC-1, VP8, VP9, MVC, etc. support up to 4K / NW1496T: MPEG-1, MPEG-2, MPEG-4, H.265, H.264, H.263, VC-1, VP8, VP9, MVC, etc. support up to 4K / NW1498T: MPEG-1, MPEG-2, MPEG-4, H.265, H.264, H.263, VC-1, VP8, VP9, MVC, etc. support up to 4K / NW1495T: MPEG-1, MPEG-2, MPEG-4, H.265, H.264, H.263, VC-1, VP8, VP9, MVC, AV1, etc., support up to 8K@60fps
Audio Format
MP3/WMA/AAC/WAV/OGG, etc
JPEG/PNG/GIF,etc
Color
White/Black
VESA
100mm × 100mm
Button
Power/Vol+/Vol-
G-sensor
Support
Speaker
4Ω/3W*2
Microphone
Standard dual Microphone, Support noise reduction and echo cancellation
NFC
Optional, 13.56MHz, ISO/IEC 18092, ISO/IEC 21481, ISO/IEC 14443 A&B, ISO/IEC 15693, Japanese Industrial Standard (JIS) (X) 6319-4, MIFARE Classic encrypted tags and cards
Camera
Optional External USB type camera (vertical portrait , 8.0MP with wide-angle and wide dynamic)
Language
Multi-language
Certificates
CCC/CE/FCC
Operating Temperature
0℃-40℃
Storage Temperature
-20℃-60℃
Operating Humidity
20~80%RH
Storage Humidity
10~95%RH
