Touchscreen Signages 8"-55"
NW2193T 21.5" Touchscreen Signage
Quick Specifications
- Diagonal Size21.5-inch (LCD)
- Panel TypeIPS
- Resolution1920 x 1080 pixels
- Aspect Ratio16:9
- Number of Colors16.7M Colors
- Color Gamut72% NTSC
Product Overview
Detailed description is not available.
Technical Specifications
Diagonal Size
21.5-inch (LCD)
Panel Type
IPS
Resolution
1920 x 1080 pixels
Aspect Ratio
16:9
Number of Colors
16.7M Colors
Color Gamut
72% NTSC
Viewing Angle
R/L 89/89, U/D 89/89
Display Mode
Normally black
Contrast Ratio
3000:1
Response Time
7ms
Back-light Type
Eled
Luminance
250 nits
Number of Points
10-point
Interface for Touch
USB
CPU
NW2193T: RK3399 Dual-core cortex A72+Quad-core cortex A53NW2196T: RK3566 Quad-core cortex A55NW2198T
RAM
NW2193T: 2GB (Optional 4GB)NW2196T: 2GB (Optional 4GB)NW2198T: 2GB (Optional 4GB)NW2195T: 4GB (Optio
ROM
NW2193T: 16GB (Optional 32GB)NW2196T: 16GB (Optional 32GB)NW2198T: 16GB (Optional 32GB)NW2195T: 32GB
Operating System
NW2193T: Android 12NW2196T: Android 12NW2198T: Android 12NW2195T: Android 12
Dimensions
512.8 x 308.9 x 33.5 mm (L × W × D)
WiFi
NW2193T: IEEE 802.11b/g/n/a/acNW2196T: IEEE 802.11b/g/nNW2198T: IEEE 802.11b/g/nNW2195T: IEEE 802.11
USB
NW2193T: USB 3.0 HostNW2196T: USB 3.0 HostNW2198T: USB 3.0 HostNW2195T: USB 3.0 Host*2
USB Type-C
NW2193T: Full Function (Except for charging function)NW2196T: USB OTG OnlyNW2198T: USB OTG OnlyNW219
HDMI
NW2193T: Support 800*600, 1024*768, 1280*720, 1280*800, 1280*1024, 1366*768, 1600*900, 1920*1080, et
Power Port
DC power input
Video Format
NW2193T: MPEG-1, MPEG-2, MPEG-4, H.265, H.264, H.263, VC-1, VP8, VP9, MVC, etc. support up to 4KNW21
Audio Format
MP3/WMA/AAC/WAV/OGG, etc
JPEG/PNG/GIF,etc
Color
White/Black
VESA
100mm × 100mm
Button
Power/Vol+/Vol-
G-sensor
Support
Speaker
4Ω/5W*2
Microphone
Standard dual Microphone, Support noise reduction and echo cancellation
NFC
Optional 13.56MHz，ISO/IEC 18092, ISO/IEC 21481, ISO/IEC 14443 A&B, ISO/IEC 15693, Japanese Industria
Camera
Optional External USB type camera (vertical portrait, 8.0MP with wide-angle and wide dynamic)
Language
Multi-language
Certificates
CCC/CE/FCC
Operating Temperature
0℃-40℃
Storage Temperature
-20℃-60℃
Operating Humidity
20~80%RH
Storage Humidity
10~95%RH
